Aerosol generator

Aerosol Generator for HEPA filters testing/Integrity /PAO/DOP testing

aerosol generator

Air flow range 50 – 2,000cfm/min(1.4-56.6m3/min)  built-in pump                                                       (one function)
Aerosol concentration 100ug/l, flow of 472.5cfm/min
  10ug/l,   flow of 4725cfm/min
Generator type 1-4 Laskin Nozzles
Aerosol type PAO,DOP, polydispersed
Compressed air Voltage source: build-in air compressor, no needing external air source
Overall dim.(mm) (37cm L* 26cm W *23cm H)
Gas type Varied diametric particle(cold)
Weight 15 KG
Power supply

Optional

 220 VAC / 50Hz

Hose adapter for AG60
Category:

AG-60 Aerosol Generator

AG-60 is a small, light and rugged portable, self-contained Laskin-Nozzle aerosol generator. It can generate aerosol of 10ug/l to 100ug/l with airflow 50cfm/min to 2000cfm/min. Laskin-Nozzle aerosol generators is with rugged stainless steel structure, big filling port, independent spray-head and pressure control, and normative and  clean joint output.

AG-60 aerosol generator has 4 pieces of Laskin-nozzle. When with the pressure of 20 psig, it works and is diluted by the air of 200CFM,gas concentration approaching 100ug/l. Built-in control valve can make 1 or 4 Laskin-Nozzles work to supply a wide range of aerosol concentrations. Applications include workstations, negative-pressure filtration units, biological safety cabinets and ceiling modules, heap filters and more.
