UV VIS SPECTROPHOTOMETER (SHIMADZU 1601)

UV/Vis Spectrophotometer

Model 1601, Shimadzu, Japan

Double beam

Lighting: 50W halogen lamp (long-life 2000 hour), Deuterium lamp (socket type), On-board automatic light source positioning mechanism.
Stray Light: Photometric System: double beam optics
Wavelength Range: 190-1100 nm
Bandwidth: 2 nm
Scanning Speed: 3200nm/min to 160nm/min
Detector: Silicon photodiode
Optical System: Monochromator uses aberration-correcting concave blazed holographic grating
Photometric Range: Absorbance of -0.5~3.999 Abs / Transmittance of 0.0~300%
Wavelength Accuracy: +/- 0.5 nm
Wavelength Reproducibility: +/- 0.1 nm
Wavelength Display: readable to 0.1 nm
Wavelength Setting: 0.1 nm increments
Wavelength Slew Rate: about 6000nm/min
Photometric Accuracy: +/- 0.004 Abs at 1.0 Abs
Make :Shimadzu, Japan
