Liquid Born Particle Analyzer

Liquid Born Particle (LPC)

Download bruocher LPC

Detection range: 1 ~ 500μm
Detection channels 24 channels, the particle size in the range of : 1 ~ 100μm

arbitrarily set by the user, the interval 0.1μm
Sample volume : 0.2 ~ 1000ml
Sampling rate: 5 ~ 100ml / min
Test Range: 0 ~ 9999999 particles
Accuracy: ± 5% specified value
Repeatability:  RSD <2% (particle count> 1, 000 / ml, 5ml sample)
Sample volume accuracy: <± 1%
Resolution: > 90%
Best detectable concentration: 0 ~ 18, 000 particles / ml
Display Operation7-inch large-screen color LCD touch screen
Data Output built-in printer, RS232 interface, USB interface
Database software Provides data statistics, query, analysis, and storage capabilities
Power :AC 220V ± 10%, 50Hz, <80W
Ambient temperature: 10 ~ 40 ° C,
Warranty one year as per manufacturer

  • Installation free (one visit only)
  • Training (one visit only)

Make: Suzhou, Sujing Automation Instrument Equipment Co.,   Ltd. China.

Category:

With built-in mini-printer

LiquidBorn particle counter is used for detection of insoluble particles in injection, infusion, powdered injection, and particulate pollution detection of medical devices like transfusion equipment, anesthesia equipment, and drug packaging. It is of full compliance with  “USP” infusion and other national standards..

LPC is using laser block method, with import semiconductor laser light source of long life and high stability; 24 detection channels; Imported precision syringe pump sampling control system, high precision sampling, sampling volume is set arbitrarily; 7 inch true color large-screen LCD touch display, built-in calibration curves and powerful database management module, easy to operate; USB interface, data storage is not restricted, you can easily transfer data and save them to your computer.
